Bluefin Underwater Light Orca

Bluefin Underwater Light Orca

HTML Editor - Full Version

Bluefin Orca O48CC surface mounted colour change underwater light. 12,000 Lumens, 24V. Bronze.

Almost endless colour combinations to choose from, lights can be sequenced, strobed, dimmed or beat to the sound of your music choice with Bluefin LED unique "sound to light feature". RGBW with DMX functionality. A radical departure from conventional sealing methods the Orca has an unique rear cassette design with multiple sealing systems.

Code Image Product Details Stock RRP Download
O20-SM-B208
Bluefin Underwater Light Orca
Cobalt blue, 24v, Surface Mount
Stock Level:
Low Stock
$2,039.00 Incl. GST
O20-SM-G209
Bluefin Underwater Light Orca
Green, 24v, Surface Mount
Stock Level:
Low Stock
$2,039.00 Incl. GST
O20-SM-W207
Bluefin Underwater Light Orca
White, 24v, Surface Mount
Stock Level:
Low Stock
$2,039.00 Incl. GST
O48-SM-CC210
Bluefin Underwater Light Orca
Colour change, 24v, Surface Mount
Stock Level:
Low Stock
$3,489.00 Incl. GST

Mounting Type: Surface

Hole cut out size: 22mm

Maximum Lamp Lumens:

  • OR20: 13,000
  • OR48: 15,000

Fixture Lumens:

  • OR20: 14,500
  • OR48: 12,000

Max Wattage:

  • OR20: 122 Watts
  • OR48: 155 Watts

Typical Life Expectancy: 50,000 hours

Voltage: 24v

Power Draw: 2.6 Amps

Protection: Over / Under Voltage, Over Current, Reverse Polarity protection, Thermal protection. MLST Sealing technology

Fixture Profile: 32mm

Fixture Diameter: 140mm

Lens Type: Optical grade 8mm Borosilicate glass with Guard X coating

Fixture Material: AB2 Bronze

Beam Angle: 65 Degree FWHM

Warranty: 2 year

Type Approval: RINA IEC 60529

Available Colours:

  • OR20: Diamond White 6500k, Emerald Green & Cobalt Blue
  • OR48: RGBW Colour change

Features: (OR48) Endless colours, cycling, strobe, dimmer or sound to light

Suitable Use: Below the water-line only

Spacing: 1.2 - 2mtr

Driver Type:

  • OR20: Integral
  • OR48: External IP67 Plug and play remote box with DMX/WIFI control. Must purchase the WIFI/DMX Controller for functions

Total weight: 2.3kg

Attatched cable length:

  • OR20: 1.8mtr Over-moulded
  • OR48: 1.8mtr Plug & play

OR20 & OR48 CC Included in the box:

  • In-line fuse holder & rated fuse
  • Gel connector
  • Inline Crimps
  • Heat shrink
  • Fixing Screws
  • Template
  • Installation instructions
