Raymarine B45 600W Bronze Thru-Hull Transducer with Fairing Block
The B45 is our smallest and most economical, dual-frequency, bronze, stem transducer. The included fairing streamlines the transducer and increases the performance—even at higher speeds.
Features:
- Depth and fast-response water-temperature sensor
- 600 W
- Dual-frequency element:
- 50 kHz with a wide 45° beamwidth for depth performance to 353 m (1,200')
- 200 kHz with a 12° beamwidth for depth performance to 206 m (700')
- Excellent performance and sensitivity in a small housing
- Bronze-stem housing with high-performance fairing for optimal performance at speed
- Bronze transducer housing
Owner's Guide & Installation Instruction
High-Performance Fairing
Airmar EMEA Brochure
Theory of Operation 2014
Weight: 2.5 kg (5.5 lb.)
Recommended Boat Length: Up to 9 m (30’)
Hull Material: Fiberglass or wood
Hull Deadrise: Up to 26° with fairing
Acoustic Window: Urethane
Hole Diameter: 22 mm or 7/8"
Includes: High-performance fairing and mounting hardware
| Code | Image | Product Details | Stock | Price | Quantity | Enquire |
|---|---|---|---|---|---|---|
|
E26019-PZ
|
|
E26019-PZ
Instrument Connectors
Stock Level:
Pre-Order, Stock Incoming
|
Stock Level:
Pre-Order, Stock Incoming
|
$714.21
|
|
